HYUNDAI POWERPACK /
GENERATOR ENGINES
Diesel engines are manufactured at the INCHEON plant in South Korea, located near the capital city of Seoul. The engines are based on the product line of the German vehicle and engine manufacturer MAN. Through a licensing agreement, Hyundai has further developed the MAN engines to fully meet modern-day requirements. The engine series includes six-cylinder inline engines with displacements of 5.8, 8.1, and 11.1 liters. Hyundai marine diesel engines are also available as V-type engines with displacements of 14.6, 18.3, and 21.9 liters. The most powerful V-engine delivers up to 1,200 horsepower.
Hyundai’s lightweight and compact engines are based on a licensing collaboration with the Japanese company ISUZU; however, these are not currently available as marine diesel engines.
HD Hyundai Infracore is removing the Doosan name and strengthening its position as a member of HD Hyundai, a year and a half after the acquisition.
HYUNDAI HEAVY DUTY – INDUSTRIAL ENGINES – DP SERIES
Type | Hp / rpm | Number of cylinders | Displacement (l) |
207 Hp (152 Kw) @ 1500 Rpm |
6 | 8 | |
207 Hp (152 Kw) @ 1500 Rpm |
6 | 8 | |
321 Hp (437 Kw) @ 1500 Rpm |
6 | 11 | |
DP126LB
| 362 Hp (492 Kw) @ 1500 Rpm | 6 | 11 |
DP158LC
| 610 Hp (449 Kw) @ 1500 Rpm | V8 | 15 |
DP158LD
| 693 Hp (510 Kw) @ 1500 Rpm | V8 | 15 |
DP180LA
| 750 Hp (552 Kw) @ 1500 Rpm | V10 | 18 |
DP180LB
| 832 Hp (612 Kw) @ 1500 Rpm | V10 | 18 |
DP222LB
| 903 Hp (664 Kw) @ 1500 Rpm | V12 | 22 |
DP222LC
| 983 Hp (723 Kw) @ 1500 Rpm | V12 | 22 |
DP222CB
| 1074 Hp (790 Kw) @ 1500 Rpm | V12 | 22 |
DP222CC
| 1190 Hp (875 Kw) @ 1500 Rpm | V12 | 22 |
Type |
Hp / rpm
| Number of cylinders | Displacement (l) |
D1146
|
116 Hp (85 Kw) @ 1500 Rpm
| 6 | 8 |
D1146T
|
160 Hp (118 Kw) @ 1500 Rpm
| 6 | 8 |
P086TI-I
|
223 Hp (164 Kw) @ 1500 Rpm
|
6 |
8 |
P086TI
|
270 Hp (199 Kw) @ 1500 Rpm
|
6 |
8 |
P126TI
|
370 Hp (272 Kw) @ 1500 Rpm
|
6 | 11 |
P126TI-II
|
294 Hp (400 Kw) @ 1500 Rpm
| 6 | 11 |
P158LE
|
563 Hp (414 Kw) @ 1500 Rpm
| V8 | 15 |
P158FE
|
675 Hp (496 Kw) @ 1500 Rpm
|
V10
| 18 |
P180FE
|
675 Hp (496 Kw) @ 1500 Rpm
|
V10
| 18 |
P222FE
|
832 Hp (612 Kw) @ 1500 Rpm
| V12 | 22 |
Technical specifications are subject to change and should always be verified with the importer or the manufacturer.
